VLHDMICLT3 – HDMI 5V & EDID Manager
The VLHDMICLT3 is a versatile HDMI management tool designed to handle both 5V power and EDID control. Its primary function is to remove the 5V signal in HDMI connections. The device automatically controls the 5V output based on the presence of a video signal in the cable.
Additionally, it can be used to manage and adjust signal resolutions from source/ devices. Configuration is simple and intuitive, thanks to the front-mounted DIP switches that allow quick and easy setup.
Also there is a possibility to do HDCP control via DIP switch (set unit as non HDCP compliant) can improve compatibility when several of products are connected.
The CEC pass-through can be turned on/off by DIP switch
